Breaking the captivity

of leveling before getting fixed.

Data Sheet

EN
Neon Spheres

A new core

Mk-803 logo Mk2.png

Thanks to the SoC (System on Board) technology, the next-generation mainboard Mk-803 now provides exceptional positioning performance in more challenging environments.

965
channels

Similar to a highway, more channels mean more lanes, which implies more incoming and outcoming data with faser and smoother flow. Mk-803 mainboard supports 965 channels,  provides a super highway for our datalink.

5
sattelite systems

16
frequencies

+


BeiDou
GPS

GLONASS
Galileo
QZSS

B1I, B2I, B3I, B1c, B2a
L1C, L2W, L2Q
G1C, G2P
EC1, E5a, E5b
L1C, L2S, L5Q

3-Freq
Algorithm

An unique algorithm by automatically picking 3 from 5 BeiDou frequencies which have the best conditions to realize incredibly fast and accurate fix.

Measure more dynamically.

IMU logo MK3.png

By measuring and reporting our receiver's specific force, angular rate, and sometimes orientation via a combination of accelerometers, gyroscopes and magnetometer, Rimu Technology enables surveyor to measure dynamically with an estimated position and head if the receiver loses satellite connection or under a poor condition of satellite signals (e.g. near tunnels, buildings, etc).

Rimu provides reliable and accurate tilt compensation for RTK, and surveyor can measure without alignment, and no longer needs to level the receiver before getting fixed.


Easy Initializtion

5-8 seconds shaking left-right to get initialization.


Accurate

<2cm within 30° tilt

<5cm within 60° tilt


Fast Re-activation

By moving 1-2 seconds, we can re-activate it on the next point.

185-1851247_magnet-magnet-icon-png-trans

Immune to Magnetic

Not affected by magnetic field nearby, such as powerline.

Powerful Data Link

Up to 3W internal UHF.

FLAT with tripod shadow.png
FLAT with pole shadow.png

Easy to reach 6-8km.


410-470MHz Dual Frequency

Supports protocols:

TrimTalk450s, TrimMark3, PCCEOT, SOUTH

Radio Router

When R90i links to a reference station with only one user ID, it gets differential corrections through the cellular network, then transmits the corrections to other rovers through internal UHF as a router.

Radio Repeater

When R90i links to a base station, it gets differential corrections through internal UHF, then transmits the corrections to other rovers through internal UHF as a repeater.

* Internal radio is not available on Lite Version.

Worry-free

Power Scheme


The power supply system of R90i allows 2 batteries loaded with hot-swapping feature which ensures a non-stop operation.


PowerHub is a specifc power bank containing 4 batteries, which is able to hung on a tripod as an external power when R90i is working as a base station for a continuous operation.

Powerod 2 BLK.png

The new Powerod now supports all models of RUIDE RTK receivers.

Super thin and light, with 4800mAh capacity.

5-pin LEMO port, compartible to all RUIDE RTK receivers.

Smarter power management, extends a longer working time.

CHANGER 2.png

Worry about recharging so many batteries? QuadCharger provides you an ideal solution. You can recharge 4 batteries at one time which will be more than sufficient for one day's use for 2 receiver.


Easy and vivid for training.

Multi-GNSS Simulator for Class and Demonstration

Easy monitoring and setting via computer or phone.

WEB PC PC.jpg

WiFi Hotspot

WEB PHONE.png

Web Server

R90i is equipped with a WiFi module, which enables our computers and smartphones to connect to the receiver via hotspot. That means a lot, because we can log on RUIDE Web Server to monitor the working status and configure almost all settings of the receiver, anytime, anywhere, wirelessly.

WiFI is not available on Lite Version.

Compatible Field Software

Microsurvey-fieldgenius-Android-600x600.
RTK GO LOGO MK1.png
Coming Soon
SURVX LOGO WITH LOGO ANDROID.png

ITEM LIST
(rover)

R90i ROVER ITEM LIST.jpg
