Type-C USB supporting Fast Charge
130mm | 790g
ROVA 1s might not be the smallest and lightest with feature of AR stake out in industry.
Unlike other pocket receivers shielded with plastic housing, when you hold and lift ROVA 1s, you can feel the unique cold sensation and gravity from the Magnesium alloy housing - the gravity that implies the finest mechanics and anti-interference capability.
A new core
Thanks to the SoC (System on Chip) technology, the next-generation mainboard Mk-803 now provides exceptional positioning performance in more challenging environments.
Similar to a highway, more channels mean more lanes, which implies more incoming and outcoming data with faser and smoother flow. Mk-803 mainboard supports 1,598 channels, provides a super highway for our datalink.
B1I, B2I, B3I, B1c, B2a
L1C, L2W, L2Q
EC1, E5a, E5b
L1C, L2S, L5Q
An unique algorithm by automatically picking 3 from 5 BeiDou frequencies which have the best conditions to realize incredibly fast and accurate fix.
AR STAKE OUT
With an integrated HD camera on the bottom of ROVA 1s, you can just follow the guidance on RTK GO field app and reach the stake out point in a more efficient and intuitive way.
A new radio
Up to 2W output, extending 50% working range.
Excellent capability of perceiving and parsing weak signals in further distance.
Faster data flow with higher capacity allows an extreme short delay of differential.
Under Eagle Mode, with 1 simple click operation, all datalink parameters are auto filled. What you do is tap your finger and get ready to work.
Under Eagle Mode, in case of the connection of network between base and rover is accidentally disconnected, it will shift to radio mode automatically, guanrateeing a non-stop connection.
410-470MHz Dual Frequency
TrimTalk450s, TrimMark3, PCCEOT, SOUTH
When RTK or VRS signal sources are interrupted because of signal disruption or temporary disconnection with radio, ROVA 1 can still be backed up by seamless and accurate positioning via an unique algorithm for up to 5 minumtes, which enables our receiver to continue quality performance and accuracy.
Rimu2.0 Technology enables surveyor to measure dynamically with an estimated position and head if the receiver loses satellite connection or under a poor condition of satellite signals (e.g. near tunnels, buildings, etc.).
Rimu2.0 provides reliable and accurate tilt compensation for RTK, and users can measure without alignment. Surveyor no longer needs to level the receiver before getting fixed.
5-8 seconds shaking left-right to get initialization.
<3cm within 30° tilt
<5cm within 60° tilt
By moving 1-2 seconds, we can re-activate it on the next point.
Immune to Magnetic
Not affected by magnetic field nearby, such as powerline.
Easy monitoring and setting via computer or phone.
Rova 1s is equipped with a WiFi module, which enables our computers and smartphones to connect to the receiver via hotspot. That means a lot, because we can log on RUIDE Web Server to monitor the working status and configure almost all settings of the receiver, anytime, anywhere, wirelessly.
Compatible Field Software
1. Internal UHF radio is not equipped on Lite Edition
2. WiFi module is not equipped on Lite Edition.
